Piezo Ceramic Tube
This piezo ceramic cylinder is radial mode vibration and is ideal for precision ultrasonic applications where compact size, resonant efficiency, and reliability are critical. Its 169 kHz frequency balances penetration depth and resolution, making it versatile for industrial and medical systems.
Service Hotline
Keywords:
Passive Piezo Buzzer、Active Piezo Buzzer、Piezo Element、Piezo Ultrasonic Component、Piezo Speaker
Category:
■ Product Description
This piezo ceramic cylinder is radial mode vibration and is ideal for precision ultrasonic applications where compact size, resonant efficiency, and reliability are critical. Its 169 kHz frequency balances penetration depth and resolution, making it versatile for industrial and medical systems.
■ Product Features:
• High sensitivity and efficiency at the resonant frequency.
• Compact size for integration into portable or space-constrained systems.
• Low power consumption compared to electromagnetic actuators.
■ Applications
Ultrasonic Flow Meters, Level Sensors, Industrial Cleaning, Acoustic Actuators and medical devices……
■ Data Sheet
No. | Model number | KDCC21x18.2x10-169K |
1 | Dielectric Loss | Tanδ≤0.5% |
2 | Static Capacitance | C0=5.2nF±10% at 1kHz |
3 | Piezoelectric Constant | d33≥285 pC/N |
4 | Operating Temperature Range | -20℃～+70℃ |
■ Dimension Drawing
Why Choose Our Piezo Buzzer
Piezo buzzers has been more and more popularily used as there is no magnetic field and no coil inside. Typically, piezo buzzers consume less current (less than 30mA), have a broader frequency range (2-6kHz) and wider operating voltage (3- 250V), and generate a higher SPL.
Kailitech piezo buzzers include types of taping, SMD, ultra-low frequency, high SPL, waterproof, high temperature and pressure resistant, with diameter or length and width fm 9.0mm to 100mm, height fm 1.8mm to 65mm, with resonant frequency range fm 200Hz to 15kHz and SPL range fm 65dB to 120dB. Housing material can be ABS, PBT, PPO, LCP, etc.
The main characteristics of Piezo Buzzers are >>
Smaller size, lighter weight, suitable for installation on various circuit boards.
High electric – acoustic power conversion efficiency (above 75%) .
Low power consumption, P≤3V*10mA=0.03W.
High reliability, long durability. The performance and degradation is the log relationship, and the degradation of performance is less than about 5% in 30 years.
No magnetic field, no coil, no electromagnetic interference.
Peizo Buzzers' Markets
Home Appliances
Medical Devices
Safety & Security
Transportation Equipment
Consumer Electronics
IOT
They all chose us
With 30 years of research and development experience, Kailitech is professional in design and develop piezoelectric components according to customer applications. "Customer-oriented, honest and trustworthy, innovative and continuously upgrading" is our aim. Kailitech will consistently provide customers with product value and technical services with rich industry experience and professional knowledge.
FAQ
What are the piezo sound component called?
Piezo Elements, Sounders, Transducers, buzzers, Audio alarms and indicators, and various combinations of these terms.
How does Kailitech sound component part number system works?
Kailitech part number system.
Please give me diagrams of the Feedback Electrode Shape and Recomend Driving Circut of your self drive type piezo transducers.
Recomend Driving Circut for seld drive piezo transducers.
Feedback electrode shape.
What are the mounting options?
Pin-type, Pin-type taping, SMD, Flange Mount & Terminal type.
What tones are available?
Continuous, Fast Pulse, Ultra Loud Siren, Ultra Loud Warble Series, and Continuous/Pulse Dual Tone.
How are they constructed?
Exploded piezo buzzer Diagram.
What are the mounting options?。
Pin-type, SMD, Flange Mount, Terminal type and Panel Screw Terminals.
